Square Terminal

The Square Terminal is expertly designed for optimal electrical connections in automotive applications. Made from high-quality materials, it offers durability and reliable performance in demanding environments. Its robust square shape enhances stability during installation and ensures secure connections that withstand vibrations and thermal fluctuations. This terminal is crucial for efficient power transmission, contributing to the overall reliability and safety of automotive electrical systems.

APPLICATIONS

TypeConnection RangeNameMaterialsPackage
Custom0.75-1.56.3 Square InsertH62Y2Disc
Wire Insulator MaterialFEP / PVC
TypeCustom
Connection Range0.75-1.5
Name6.3 Square Insert
MaterialsH62Y2
PackageDisc

Product Features

RELATED PRODUCTS

This Might Interest You

● Usage:Electrical connection

Designed for durability, this housing features one round and eight flat holes, ensuring secure, reliable connections.

● Usage:Pressure Measurement

Utilizing advanced technology, this sensor delivers accurate pressure readings for automotive, medical, and industrial applications.

● Usage:ECU Integration

Enables efficient data transfer and power delivery for precise control of battery management, motor control, and charging.

FREQUENTLY ASKED QUESTIONS

Your Question Is Answered

The lifespan of a connector typically depends on the usage environment and frequency of use. Generally, high-quality connectors can withstand thousands of insertion and removal cycles under normal conditions.

When selecting a connector, consider the following factors:

• Application environment: temperature, humidity, vibration, etc.
• Electrical requirements: necessary voltage, current, and impedance.
• Size and shape: ensure compatibility with existing equipment.

Installation steps typically include:

• Ensure the power is turned off.
• Align the connector, ensuring the pins on the plug and socket fit correctly.
• Apply even pressure to insert until you hear a “click,” indicating it is locked in place.

If you experience poor contact, try the following:

• Check if the connector is securely inserted.
• Clean the contact surfaces to remove dust and debris.
• Inspect the connector for damage; if damaged, replace it.

Many connectors are designed to be waterproof and weather-resistant, but for outdoor use, it’s best to select connectors specifically designed for such environments, ensuring they meet the required protection ratings.

We provide customization services for connectors, including special sizes, materials, and electrical specifications. Please contact our technical support for more information.

To extend the lifespan of connectors, we recommend regularly checking and cleaning them. Avoid storing them in high-temperature or humid environments, and refrain from excessive pulling on cables during use.
